Bundle Rack - 3 meters long. (9’ 10”)
General
The Aardwolf bundle racks consist of a pair of galvanized steel rails 3m long, together with rectangular galvanized steel tube posts. The rectangular post can be positioned anywhere along with the rack. All posts are manufactured from rectangular tube steel with a minimum yield strength of 345Mpa, with 5mm wall thickness, ensuring safety for the vertical storage of slab bundles.
Features
- + The maximum number of marble or granite slabs that can be safely stored per bay at a 4° lean depends on the slab thickness and dimensions.
- + Aardwolf has developed a simple calculator specifically to calculate the slab storage capacity.
- + Post available in 4 standard heights of 1200mm, 1400mm, 1600mm, 1800mm.
Specifications
| ABR10 |
Metric
(mm-kg)
|
Imperial
(inch-lb)
|
| Galvanised steel rail | 2925 x 164 x 165 | 115.1'' x 6.45'' x 6.5'' |
| Rack height | 165 | 6.5'' |
| Rectangular hole | 101.5 x 52 | 4 x 2'' |
| Increment | 111.5 | 4.4'' |
| Rectangular tube post | 100 x 50 | 3.9'' x 2'' |
| Posts wall thickness | 5 | 0.2'' |
| Rectangular rubber post caps | 100 x 50 | 3.9'' x 2'' |
| Timber battens per rail | 50 x 25 | 2'' x 1'' |
| Net weight | 77.7/PCS | 171 |
| Gross weight | 78 | 171 |
| Packaging dimensions | 2925 x 165 x 165 | 115' 'x 6.5'' x 6.5'' |
